Foundations

Differentiation in Rn

Partial derivatives, the gradient, directional derivatives, the total derivative (Frechet), and the multivariable chain rule. Why the gradient points in the steepest ascent direction, and why this matters for all of optimization.

CoreTier 1Stable~40 min

Prerequisites

Sets Functions and Relations

Quiz (3)

Why This Matters

Gradient descent is the workhorse of machine learning. Every neural network, every logistic regression, every optimizer computes a gradient and steps in the negative gradient direction. Understanding what the gradient is, why it points in the direction of steepest ascent, and how the chain rule composes derivatives through layers is prerequisite for understanding any optimization method.

Partial Derivatives

Definition

Partial Derivative

For $f: \mathbb{R}^n \to \mathbb{R}$ , the partial derivative with respect to the $i$ -th variable at point $a$ is:

$\frac{\partial f}{\partial x_i}(a) = \lim_{h \to 0} \frac{f(a + h e_i) - f(a)}{h}$

where $e_i$ is the $i$ -th standard basis vector. This measures the rate of change of $f$ when only $x_i$ varies and all other variables are held fixed.

Partial derivatives exist whenever the function is differentiable along coordinate directions. But the existence of all partial derivatives does not guarantee that $f$ is differentiable in the full sense. The total derivative (below) is the correct generalization.

The Gradient

Definition

Gradient

For $f: \mathbb{R}^n \to \mathbb{R}$ with all partial derivatives existing at $a$ , the gradient is the vector of partial derivatives:

$\nabla f(a) = \left(\frac{\partial f}{\partial x_1}(a), \ldots, \frac{\partial f}{\partial x_n}(a)\right)^T \in \mathbb{R}^n$

The gradient lives in the same space as the input $a$ .

Directional Derivative

Definition

Directional Derivative

For a unit vector $v \in \mathbb{R}^n$ ( $\|v\| = 1$ ), the directional derivative of $f$ at $a$ in direction $v$ is:

$D_v f(a) = \lim_{t \to 0} \frac{f(a + tv) - f(a)}{t}$

When $f$ is differentiable at $a$ : $D_v f(a) = \nabla f(a)^T v$ .

The Gradient Points in the Steepest Ascent Direction

Theorem

Gradient as Steepest Ascent Direction

Statement

Intuition

The directional derivative $\nabla f(a)^T v$ is the dot product of the gradient with the direction. By the Cauchy-Schwarz inequality, this is maximized when $v$ is aligned with $\nabla f(a)$ and minimized when $v$ is opposite. The gradient direction is the direction of fastest increase; the negative gradient is the direction of fastest decrease.

Proof Sketch

Why It Matters

This is the theoretical justification for gradient descent. To decrease a loss function $\mathcal{L}(\theta)$ as quickly as possible per unit step, move in the direction $-\nabla \mathcal{L}(\theta)$ . This idea is the foundation of convex optimization. Every gradient-based optimizer (SGD, Adam, Adagrad) uses the negative gradient as its primary signal.

Failure Mode

The gradient gives the steepest descent direction only for infinitesimal steps. For finite step sizes, the actual decrease depends on the curvature (second derivatives). A large step in the gradient direction can overshoot and increase the loss. This is why learning rate selection matters, and why second-order methods (Newton's method, natural gradient) consider curvature.

Total Derivative (Frechet Derivative)

Definition

Total Derivative

A function $f: \mathbb{R}^n \to \mathbb{R}^m$ is (Frechet) differentiable at $a$ if there exists a linear map $L: \mathbb{R}^n \to \mathbb{R}^m$ such that:

$\lim_{h \to 0} \frac{\|f(a + h) - f(a) - Lh\|}{\|h\|} = 0$

The linear map $L$ is the total derivative $Df(a)$ . It is represented by the $m \times n$ Jacobian matrix. For $f: \mathbb{R}^n \to \mathbb{R}$ (scalar-valued), $Df(a) = \nabla f(a)^T$ is a row vector.

The total derivative is the correct notion of differentiability for multivariable functions. It says: $f$ near $a$ is well-approximated by its linearization $f(a) + Df(a)(x - a)$ .

Chain Rule in Multiple Variables

Theorem

Multivariable Chain Rule

Statement

If $g: \mathbb{R}^n \to \mathbb{R}^k$ is differentiable at $a$ and $f: \mathbb{R}^k \to \mathbb{R}^m$ is differentiable at $g(a)$ , then the composition $f \circ g$ is differentiable at $a$ and:

$D(f \circ g)(a) = Df(g(a)) \cdot Dg(a)$

The derivative of the composition is the product of the Jacobian matrices.

Intuition

Each differentiable function is locally linear. Composing two locally linear maps gives a locally linear map, and the matrix of the composition is the product of the matrices. This is just the chain rule from single-variable calculus generalized to matrices.

Proof Sketch

Let $L_f = Df(g(a))$ and $L_g = Dg(a)$ . By differentiability of $g$ : $g(a + h) = g(a) + L_g h + o(\|h\|)$ . By differentiability of $f$ : $f(g(a + h)) = f(g(a) + L_g h + o(\|h\|)) = f(g(a)) + L_f(L_g h + o(\|h\|)) + o(\|L_g h + o(\|h\|)\|)$ . Since $L_f$ is linear, this equals $f(g(a)) + L_f L_g h + o(\|h\|)$ . So $D(f \circ g)(a) = L_f L_g$ .

Why It Matters

Backpropagation is the chain rule applied to a computational graph. A neural network is a composition $f = f_L \circ f_{L-1} \circ \cdots \circ f_1$ , and:

$Df(a) = Df_L(z_{L-1}) \cdot Df_{L-1}(z_{L-2}) \cdots Df_1(a)$

Backpropagation computes this product right-to-left (reverse mode), which is efficient because the output dimension (loss = scalar) is small.

Failure Mode

The chain rule requires both $f$ and $g$ to be differentiable. Non-differentiable activations (ReLU at zero) technically violate this, but work in practice because the set of non-differentiable points has measure zero and subgradients suffice for optimization.

Common Confusions

Watch Out

Partial derivatives existing does not imply differentiability

The function $f(x, y) = xy / (x^2 + y^2)$ for $(x,y) \neq (0,0)$ and $f(0,0) = 0$ has both partial derivatives at the origin ( $\partial f / \partial x = 0$ and $\partial f / \partial y = 0$ ) but is not continuous, let alone differentiable, at the origin. The total derivative is a strictly stronger condition than the existence of partial derivatives.

Watch Out

The gradient is not the same as the derivative

For $f: \mathbb{R}^n \to \mathbb{R}$ , the gradient $\nabla f(a)$ is a column vector in $\mathbb{R}^n$ . The total derivative $Df(a)$ is a row vector (a $1 \times n$ matrix). They contain the same information but are different mathematical objects: $Df(a) = \nabla f(a)^T$ . This distinction matters when composing derivatives via the chain rule.

Watch Out

Gradient descent works on parameters, not inputs

In ML, you compute $\nabla_\theta \mathcal{L}(\theta)$ , the gradient with respect to model parameters $\theta$ . You do not optimize over inputs $x$ . The gradient tells you how to change $\theta$ to reduce the loss, not how to change the data.

Summary

Partial derivative: rate of change along one coordinate axis
Gradient: vector of all partial derivatives; lives in input space
The gradient points in the direction of steepest ascent (Cauchy-Schwarz)
Total derivative (Frechet): the best linear approximation to $f$ near $a$
Chain rule: $D(f \circ g)(a) = Df(g(a)) \cdot Dg(a)$ , i.e., multiply Jacobians
Backpropagation is the chain rule applied right-to-left through a neural network

Exercises

ExerciseCore

Problem

Let $f(x, y) = x^2 y + e^{xy}$ . Compute $\nabla f(1, 0)$ and find the directional derivative in the direction $v = (3/5, 4/5)$ .

ExerciseAdvanced

Problem

A two-layer neural network computes $f(x) = \sigma(W_2 \sigma(W_1 x))$ where $\sigma$ is applied elementwise and $W_1 \in \mathbb{R}^{k \times n}$ , $W_2 \in \mathbb{R}^{1 \times k}$ . Use the chain rule to write $\partial f / \partial W_1$ in terms of the Jacobians of each layer.

References

Canonical:

Rudin, Principles of Mathematical Analysis (1976), Chapter 9
Spivak, Calculus on Manifolds (1965), Chapter 2
Apostol, Mathematical Analysis (1974), Chapter 12 (multivariable differential calculus)

Current:

Goodfellow, Bengio, Courville, Deep Learning (2016), Chapter 4 (Numerical Computation)
Boyd & Vandenberghe, Convex Optimization (2004), Appendix A.4 (gradients and Hessians)
Deisenroth, Faisal, Ong, Mathematics for Machine Learning (2020), Chapter 5 (vector calculus)

Next Topics

The Jacobian matrix: the full matrix of partial derivatives for vector-valued functions
Convex optimization basics: using gradients to solve optimization problems
Automatic differentiation: computing gradients efficiently via computation graphs
